| Device Type |
Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type |
Desktop,rack-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
48 x 10/100/1000 + 2 x 10 Gigabit SFP+ |
| Performance |
Switching capacity:176 Gbps
Forwarding performance:130.95 Mpps |
| Capacity |
IPv4 routes:24000
NetFlow entries:48000
Virtual interfaces (VLANs):4000
Switched virtual interfaces (SVIs):1000 |
| MAC Address Table Size |
32000 entries |
| Jumbo Frame Support |
9198 bytes |
| Routing Protocol |
BGP-4,IS-IS,RIP-1,RIP-2,PIM-SM,static IP routing,PIM-DM,EIGRP for IPv6,OSPFv3,PIM-SSM,policy-based routing (PBR),RIPng |
| Remote Management Protocol |
SNMP 1,RMON 1,RMON 2,RMON 3,RMON 9,Telnet,SNMP 3,SNMP 2c,SSH,CLI |
| Authentication Method |
Secure Shell (SSH),RADIUS,TACACS+ |
| Features |
Layer 2 switching,ARP support,trunking,VLAN support,IGMP snooping,IPv6 support,Rapid Spanning Tree Protocol (RSTP) support,Multiple Spanning Tree Protocol (MSTP) support,DHCP snooping,Port Aggregation Protocol (PAgP) support,Access Control List (ACL) support,Quality of Service (QoS),RADIUS support,Virtual Route Forwarding-Lite (VRF-Lite),MLD snooping,Dynamic ARP Inspection (DAI),Uni-Directional Link Detection (UDLD),Rapid Per-VLAN Spanning Tree Plus (PVRST+),Link Aggregation Control Protocol (LACP),Remote Switch Port Analyzer (RSPAN),Energy Efficient Ethernet,Flexible NetFlow (FNF) |
| Compliant Standards |
IEEE 802.3,IEEE 802.3u,IEEE 802.3z,IEEE 802.1D,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.1p,IEEE 802.3af,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.1w,IEEE 802.1x,IEEE 802.1s,IEEE 802.1ab (LLDP),IEEE 802.3at |
| RAM |
4 GB |
| Flash Memory |
2 GB |
| Status Indicators |
Port transmission speed,port duplex mode,system,active,status |
| Expansion / Connectivity | |
|---|
| Interfaces |
48 x 1000Base-T - RJ-45
1 x USB - Type A
1 x serial (console) - RJ-45 - management
1 x management (Gigabit LAN) - RJ-45 - management
1 x management (mini-USB) - Type B - management
2 x 1000Base-X - SFP - uplink
2 x 10GBase-X - SFP+ - uplink |
| Expansion Slots |
1 (total) / 1 (free) x Stacking Module |
| Power | |
|---|
| Power Device |
Internal power supply - hot-plug |
| Installed Qty |
1 (installed) / 2 (max) |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Power Provided |
250 Watt |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
|---|
| Rack Mounting Kit |
Included |
| MTBF |
527,580 hours |
| Compliant Standards |
CISPR 22 Class A,GOST,BSMI CNS 13438 Class A,CISPR 24,EN 61000-3-2,NOM,EN 61000-3-3,EN55024,EN55022 Class A,ICES-003 Class A,RoHS,UL 60950-1 Second Edition,KCC,FCC Part 15 A,ISO 7779,CSA C22.2 No. 60950-1 Second Edition,EN 60950-1 Second Edition,IEC 60950-1 Second Edition,VCCI Class A,KN24,KN22 Class A |
