Cisco WS-C3650-48FQ-E IP Service Switch

Cisco WS-C3650-48FQ-E IP Service Switch

Add to Wish List
AED 14,709.75
Be the first to review this product

The Cisco Catalyst® 3650 Series is the next generation of enterprise-class standalone and stackable access-layer switches that provide the foundation for full convergence between wired and wireless on a single platform. The Cisco Catalyst 3650 is built on the advanced Cisco StackWise®-160, and takes advantage of the new Cisco® Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. The Cisco Catalyst 3650 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), and offer modular and field-replaceable redundant fans and power supplies. They can help you increase wireless productivity and reduce your TCO.

Add to Compare
In stock
SKU
WS-C3650-48FQ-E
CiscoSwitchesCatalyst Switches

Guarantee safe & secure checkout

Management features
Switch type Managed
Web-based management Yes
Quality of Service (QoS) support Yes
Multicast support Yes
Switch layer L3
Ports & interfaces
SFP+ module slots quantity 4
Basic switching RJ-45 Ethernet ports quantity 48
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Networking
Networking standards IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex Yes
VLAN support Yes
Spanning tree protocol Yes
Rate limiting Yes
Link aggregation Yes
IP routing Yes
IGMP snooping Yes
DHCP server Yes
Auto MDI/MDI-X Yes
10G support Yes
Data transmission
MAC address table 32000 entries
Switching capacity 176 Gbit/s
Number of VLANs 4094
Jumbo frames support Yes
Security
SSH/SSL support Yes
Access Control List (ACL) Yes
Design
Safety UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, GOST, NOM
Form factor 1U
Colour of product Black
LED indicators Yes
Certification 47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
KCC
CNS13438 Class A
EN55024
CISPR24
KN24
Rack mounting Yes
Performance
Stackable Yes
Noise level 48 dB
Memory type DRAM
Mean time between failures (MTBF) 383760 h
Internal memory 4096 MB
Flash memory 2000 MB
Power
AC input voltage 100-240 V
AC input frequency 50/60 Hz
Power consumption (typical) 114.69 W
Redundant power supply (RPS) support Yes
Number of power supply units 1
Technical details
Form factor 1U
Colour of product Black
Stackable Yes
Noise level 48 dB
Mean time between failures (MTBF) 383760 h
Rack mounting Yes
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity 48
Total Power over Ethernet (PoE) budget 775 W
Power over Ethernet (PoE) Yes
Certificates
Safety UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, GOST, NOM
Certification 47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
KCC
CNS13438 Class A
EN55024
CISPR24
KN24
Memory
Memory type DRAM
Internal memory 4096 MB
Flash memory 2000 MB
Indication
LED indicators Yes
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) -5 - 50 °C
Operating relative humidity (H-H) 5 - 96%
Operating altitude 0 - 1500 m
Non-operating altitude 0 - 5000 m
Weight & dimensions
Width 445 mm
Depth 486 mm
Height 44 mm
Weight 7.8 kg
Other features
Bandwidth 160 Gbit/s
